Products > Body Worn Camera > > DS.20 Body Worn Camera
Product name : DS.20 Body Worn Camera
Product No. : DS.20
             [Next Product]→
Online Inquiry         Email Us

  Details:

The website contains information about the technical characteristics of the basic model of the Personal chest video recorder

DS . 20



Processor

Amberalla H22

Chipset (sensor)

OV4689

Display

2.0 inch Full HD LCD display

Lens

Aperture F2.0, wide angle 170 degrees

Battery capacity

2800 mAh

Number of batteries

2

Built-in memory capacity

128 GB

Photo format

JPEG

Photo resolution

Maximum (programmatically set)

50M (40/MP/32M/16M/8M/4M)

Video resolution (programmatically set)

2688x1512 (30FPS), 2560x1440 (30 FPS), 2304x1296 (30FPS), 1920x1080 (30 FPS), 1280x720 (30 FPS), 848x480 (30 FPS)

Video frame rate

30 frames/s

Video format

MOV/AVI/MPEG4/4k

Compression format

H.264/H.265

Audio format

WAV

Sound compression

AAS

Presence of a microphone

So

Size (mm) (H*L*W)

88*62*34 mm

weight

110 g

Moisture resistance

IP68

Impact resistance

Up to 2 m

Focal length of the lens

2.8 mm

Battery charging time

3 hours

charging method

Docking station/charging via USB

Infrared night vision

15 meters

Video recording indicators

Visual, sound and tactile

White balance

In stock

Device ID, Police ID, Time and Date, GPS

In stock

The time of continuous video recording with a full charge of the battery,

848x480 (30 FPS) 20 hours, 2560x1440 (30 FPS) - 15 hours, 1920x1080p (30 FPS) - up to 8 hours ( Wi-Fi included)

Satellite positioning

Built-in GPS module

Bluetooth

Built-in Bluetooth module

Wireless data transmission systems

Built-in Wi-Fi , 802.11b/g/n, 2.4G&5G

Network protocol

CMSV6 and 808/1078 support, GB 28181

Operating temperature regime

-40°C~+60°C

Map support

SIM cards, Micro SD memory card









We also have the opportunity to supply such a model in such a configuration



Battery capacity

2300 mAh , 2800 mAh , 3100 mAh , 3200 mAh

Built-in memory capacity

32GB/64GB/128GB/256GB

Additional storage capacity (memory card - microSDHC , microSDXC )

32GB/64GB/128GB/256GB

Audio interfaces

input/ output Mini-jack (3.5 mm)

Charging cable

Magnetic contact charging/USB-C

The presence of an LED

Red, blue, green, yellow, etc

Flashlight mode

the presence of a white LED

ZUM

x 1-64



Additional software

TS , TS technology will not lose the video file if the video file is interrupted by an accidental impact during recording

Smart cyclometer

Displays useful information about the movement. Connection to the GPS module is required
